Challenges: This project is designed by the architect with two buildings placed adjacent to each other in such a way that it gives the best aesthetics with maximum space utilization. In this project, we predominantly used Unitized Curtainwall and Rain Screen ACP cladding. ACP cladding in the elevation in progressive horizontal ACP bands and features of the ACP box is creating a lot of complex and critical interfaces.
Interfacing of continuous unitized curtain wall and strip unitized curtain wall, ACP feature frame cladding support, and balcony interfaces requires proper attention and solutions.
Our approach: For unitized strip windows between progressive ACP band we suggested few structural changes during the concept design stage which has reduce the ACP by 10% and help us to limit glass wastage below 8%.
To make the stack gutter interfacing work seamless, we have shifted stack level to 720mm from FFL. All progressive ACP cladding band's horizontal surfaces are designed as walkable to take a live load to avoid any damages to cladding during routine cleaning by the maintenance team.
All critical interfaces as mentioned above are solved during design development stage.
